EPR INSULATED CABLE


EPR Rubber Insulated  Flexible Rubber  Cable, these cables are designed to provide high flexibility and have the capacity to withstand weather, oils/greases, mechanical and thermal stresses.


EPR INSULATED RUBBER CABLE

Description

EPR Rubber Insulated Flexible Rubber Cable, these cables are designed to provide high flexibility and have the capacity to withstand weather, oils/greases, mechanical and thermal stresses.

Applications include handling equipment, mobile power supplies, worksites, stage and audio visual equipment, port areas and dams. Also for use in drainage and water treatment, cold environments and severe industrial environments.

Specification:

1 EPR cables

2 Massive production

3 ISO certificate

4 Manufactured with pride in China

450/750v IEC standard EPR insulated Neoprene sheath flexible HO7RN-F rubber cable

EPR (Ethylene Propylene) Insulated Trailing Flexible Rubber Cable with Single Core or Multicore

Voltage: 450/750V

Test Voltage: 2500V

Operating Temperature Range: -20oC to +85oC

Bending Radius: 15 x Cable Diameter

Manufacturing standard: IEC, VDE

Construction:

– conductor: flexible Class5 bare or tinned copper wire stranded or solid

– insulation: EPR rubber (Ethylene Propylene)

– sheath: EPR rubber or Neoprene or CPE (Chlorinated Poly Ethylene) rubber

H07RN-F 2 Core Type 450/750V EPR insulated Rubber Cable

Core and Size

Mm sq

Stranding (Number of Strand/Strand Diameter

Thickness of Sheath mm

Nominal Overall Diameter mm

Approx. Weight kg/km

2 X 1.0

32/0.20

0.8

8.4

98

2 X 1.5

30/0.50

0.8

9.4

116

2 X 2.5

50/0.25

0.9

11

164

2 X 4.0

56/0.30

1.0

12.8

232

2 X 6.0

84/0.30

1.0

14.2

297

2 X 10.0

80/0.40

1.2

20.4

573

2 X 16.0

126/0.40

1.2

23

774

2 X 25.0

196/0.40

1.4

27.4

1110

2 X 35.0

276/0.40

1.4

30.8

1474

MORE

EPR insulated and CPE sheathed heavy duty rubber cable

Standard

IEC60245; GB/T5013; We can also manufacture rubber cable according to customer's requirements.

Application

The cables are suitable for power plant, various household appliances, power tools and various portable electrical equipments with rated voltage Uo/U of 450/750V and below.

Operation characteristics

The cables have good grounding, bending performance and high insulation performance.

Product performance

– Conductor should conform to the stipulation of conductor class 5 as per IEC60228.

– Mechanical strength: be able to withstand the normal caused by bending and other mechanical stress.

– Flexing test: During the test, by 1500 times repeated movement, that is 30,000 times one-way movement, the conductor doesn’t occur current interruption and short circuit.

Product type and name

Type

Description

245 IEC51(RX)

Braided flexible cable

245 IEC53(YZ)

General strength rubber sheathed flexbible cable

245 IEC57(YZW)

General neoprene or other equivalent synthetic elastic rubber sheathed cable

245 IEC66(YCW)

Heavy duty neoprene or other equivalent synthetic elastic rubber sheathed cable

245 IEC58(YSF)  245 IEC58(YSFB)

Decorative loop use of neoprene or other equivalent synthetic elastic rubber sheathed cable

245 IEC81(YH)

High strength rubber sheathed welding machine cable

245 IEC82(YHF)

Neoprene or other equivalent synthetic elastic rubber sheathed welding machine cable

YQ, YQW

Light type rubber sheathed flexible cable

YZ, YZW

Medium type rubber sheathed flexible cable

YZB, YZBW

Medium type rubber sheathed flat flexible cable

YC, YCW

Heavy type rubber sheathed flexible cable

RX

Rubber insulated braided flexible cable

RXS

Rubber insulated braided twisted flexible cable

RX14

Rubber insulated rubber protection layer collectively braided round shape flexible cable

MORE



Type

Rated voltage

(V)

No. of cores

Nominal Area

(mm2)

245 IEC51(RX)

300/300

3

0.75-1.5

245 IEC53(YZ)

300/500

5

0.75-2.5

245 IEC57(YZW)

300/500

5

0.75-2.5

245 IEC66(YCW)

450/750

5

1.5-2.5

245 IEC58(YSF)  245 IEC58(YSFB)

300/500

2

0.75-1.5

245 IEC81(YH)

1

16-95

245 IEC82(YHF)

1

16-95

YQ, YQW

300/300

3

0.3-0.5

YZ, YZW

300/500

5

4-6

3+1

1.5-6

6

0.75-6

YZB, YZBW

300/500

6

0.75-6

YC

450/750

1

1.5-4

2

1.5-95

4

1.5-150

5

1.5-25

3+1

2.5-150

YCW

450/750

2

35-95

3

120-150

3+1

2.5-150

RX

300/300

3

0.3-4

RXS

300/300

1

0.3-4

RX14

300/300

3

0.3-4

MORE
